Subaru Forester 2004 - Page 349

BS-3
BODY STRUCTURE
Datum Points
2. Datum Points
A: LOCATION
NOTE:
• Datum points are specified for body repair.
• Guide holes, locators, and indents are provided to facilitate panel replacement and to increase alignment
accuracy.
• Both right and left reference points are symmetrical.
BS-00001
