Combination Meter System
B: INSPECTION
CAUTION:
When measuring voltage and resistance of the ECM, TCM, or each sensor, use a tapered pin with a
diameter of less than 0.64 mm (0.025 in) in order to avoid poor contact. Do not insert the pin more
than 2 mm (0.08 in).
1. SYMPTOM CHART
Symptom Repair order Reference
Combination meter assembly does not operate. (1) Power supply
(2) Ground circuit
<Ref. to IDI-5, CHECK
POWER SUPPLY AND
GROUND CIRCUIT,
INSPECTION, Combi-
nation Meter System.>
Speedometer does not operate. (1) (MT model) Vehicle speed sensor
(AT model) TCM
(2) Harness
(3) Speedometer
MT model: <Ref. to IDI-
5, CHECK VEHICLE
SPEED SENSOR,
INSPECTION, Combi-
nation Meter System.>
AT model: <Ref. to IDI-
6, CHECK TRANSMIS-
SION CONTROL MOD-
ULE (TCM),
INSPECTION, Combi-
nation Meter System.>
Tachometer does not operate. (1) ECM
(2) Harness
(3) Tachometer
<Ref. to IDI-7, CHECK
ENGINE CONTROL
MODULE (ECM),
INSPECTION, Combi-
nation Meter System.>
Fuel gauge does not operate. (1) Fuel level sensor
(2) Harness
(3) Fuel gauge
<Ref. to IDI-7, CHECK
FUEL LEVEL SEN-
SOR, INSPECTION,
Combination Meter
System.>
Water temperature gauge does not operate. (1) Engine coolant temperature sensor
(2) Harness
(3) Water temperature gauge
<Ref. to IDI-8, CHECK
ENGINE COOLANT
TEMPERATURE SEN-
SOR, INSPECTION,
Combination Meter
System.>
Outside temperature indicator does not operate. (1) Ambient sensor
(2) Harness
(3) Combination meter
<Ref. to IDI-8, CHECK
OUTSIDE TEMPERA-
TURE INDICATOR,
INSPECTION, Combi-
nation Meter System.>
