General Description
3. HOOD GRILLE
4. HEAT SHIELD COVER
(1) Hood grille (6) Grille duct Tightening torque: N·m (kgf-m, ft-lb)
(2) Black clip (7) Clip T: 4.4 (0.45, 3.25)
(3) Black clip (8) Packing C
(4) Packing B (9) Packing A
(5) Bolt (10) Duct bellows
(1) Front heat shield cover (2) Center heat shield cover (3) Rear heat shield cover
