EB-15
EXTERIOR BODY PANEL
Rear Door Panel
2) Loosen the door-side bolts of upper and lower hing-
es to align the position of rear door panel vertically and
laterally at front-end.
3) Loosen the screw (A) and lightly tap striker (B) using
plastic hammer to adjust striker to align the position of
rear door panel vertically and laterally at the rear end.
CAUTION:
Do not use an impact wrench. The welding area
on the striker nut plate is easily broken.
EB-00015
EB-00017
(B)
(A)
To Next Page
