CRUISE CONTROL SYSTEM (DIAGNOSTIC)
General Description
C: INSPECTION
1. BATTERY
Measure the battery voltage and specific gravity of
electrolyte.
Standard voltage:
12 V, or more
Specific gravity:
Above 1.260
2. CRUISE CONTROL CABLE
1) Check the cruise control cable installation.
2) If NG, install the cable securely.
3. ACCELERATOR CABLE
1) Check the movement of accelerator cable when
the cruise control throttle is moved by hand.
2) If NG, check the throttle cam.
4. THROTTLE CAM
Check that the throttle cam moves smoothly.
If NG, repair the throttle cam.
5. CABLE FREE PLAY
1) Check that the throttle cam-to-lever clearance
(A) or cable (B) deflection amount (D) is within
specifications.
Throttle cam-to-lever clearance:
0 — 1 mm (0 — 0.04 in)
Inner cable deflection:
1 — 8 mm (0.04 — 0.31 in)
2) If NG, adjust the clearance with the adjusting
nut.
NOTE:
Check that the cap (C) is positioned in the groove.
(1) Cruise control cable
(1) Accelerator cable
