1-30 Seat, seatbelt and SRS airbags
! Installing a forward facing child
restraint
S01AG1102
First check if the Automatic Locki ng
Retractor (ALR) is eq uipped for the
seatbelts of the vehicle according to the
following procedure.
1. Draw out the seatbelt completely.
2. Retract the seatbelt even slightly and
try to draw out the seatbelt again.
3. If the seatbelt is locked in that position
and cannot be extended, it indicates that
an ALR is equipped for the seatbelt.
When the seatbelt is retracted fully, the
ALR mode is canceled and the Emer-
gency Locking Retractor (ELR) mode is
restored.
If the ALR is not equipped for the seatbelt,
refer to “
s01ag110203Models without ALR” F1-
30.
If the ALR is equipped for the seatbelt,
refer to “
s01ag110204Models with ALR” F1-31.
NOTE
. For details about the ELR, refer to
“
s01ae02Emergency Locking Retractor
(ELR)” F1-12.
. For details about the ALR, refer to
“
s01ae03Automatic/Emergency Locking
Retractor (A/ELR)” F1-13.
! Models without ALR
S01AG110203
1. Place the child restraint system in the
rear seating position.
2. Run the lap and shoulder belt through
or around the child restraint system
following the instructions provided by its
manufacturer.
3. Insert the tongue plate into the buckle
until you hear a click.
4. Take up the slack in the lap belt.
5. Before having a child sit in the child
restraint system, try to move it back and
forth and right and left to check that it is
firmly secured. Sometimes a child restraint
can be more firmly secured by pushing it
To Next Page
