Period of additional logging after triggering condition
fulfilment.
Recording of the waveform signal to a file with the
extension WAV. Files WAV are created automatically.
Every time a wave recording starts the new WAV file is
created and is closed when recording stops.
Switching on the wave recording by selecting its type:
Continuous or On Trigger. Continuous means that the
wave signal will be recorded continuously from the start
of the measurement till its end. On Trigger recording put
additional conditions for triggering and ending of the
recording.
WAV file format: PCM or Extensible. PCM is typical
supported by the audio players.
Sampling frequency of the wave recording: 12kHz,
24kHz or 48kHz. The higher sampling corresponds with
the better quality of the recorded signal but increases
size of the file.
Number of recorded bits per sample: 16 or 24.
Gain of the recorded signal, when 16 bits per sample was
selected: 0dB … 40dB.
Weighting filter during the wave signal recording: A, B, C
or Z for sound and HP for vibration. The Z filter is
recommended for audio listening.
Name of the WAV type file.
