Position in the Logger Setup screen that enables saving
of the logger records in separate files according to
different rules: after the integration period, or every
quarter / half an hour / hour, or on specific times of a day.
Screen in the Logging list enabling selecting results that
will be logged to a logger file with Logger Step as time-
histories: Peak, Max, Min, Leq, 2xLR and LXY for sound
measurements and Peak, P-P, Max and RMS for
vibration measurements as well as the series of results
obtained from the weather station (Meteo). For the
1/1 Octave and 1/3 Octave functions also spectra can be
logged.
Screen that enables configuring parameters for
triggering of Logger Results recording to the logger file:
Trigger, Source, Level, Pre and Post.
Position that switches Off or On the logger trigger by
selecting its type: Level + or Level –.
If the instrument is waiting for the trigger condition, the
appropriate trigger icon is flashing on the display
alternatively with the „logger” icon.
Type of trigger, that starts logging of Logger Results
under the condition: value of the Leq/RMS result
(Source) integrated by the Logger Step period is greater
than the threshold level (Level). In other cases, the
logging is skipped.
Type of trigger, that starts logging of Logger Results
under the condition: value of the Leq/RMS result
(Source) integrated by the Logger Step period is lower
than the threshold level (Level). In other cases, the
logging is skipped.
Measured result that is compared with the threshold level
(Level) for triggering – RMS measured in the first profile:
Leq(1) in sound modes and RMS(1) in vibration modes.
Threshold level of Source for triggering condition
fulfilment.
Period of additional logging before triggering condition
fulfilment.
