166
SVAN 977A User Manual - Appendixes
Group name
Group
code
Code description
Screen in FFT analysis
w
w0 - Hanning
w1 - Rectangle
w2 - Flat Top
w3 - Kaiser-Bessel
FFT lines
y
y0 - 1600
y1 - 800
y2 - 400
Storing the results of FFT analysis in
logger’s file
q
q0 - switched off
q8 - logger with RMS spectrum
Logger
T
T0 - switched Off
T1 - switched On
Logger Summary Results
XXE
XXE0 - switched Off
XXE1 - switched On
Logger Meteo
p
p0 - switched Off
p1 - switched On
Logger step
d
dn n = number in milliseconds (2, 5, 10, 20,
25, 50, 100, 200, 500, 1000)
dns n = number in seconds (1  60)
dnm n = number in minutes ( 1  60)
Logger Split Mode
XA
XA0 Off
XA-1 Sync to the Integration Period
XA15 Sync. to the full 15 minutes
XA30 Sync. to the full 30 minutes
XA60 Sync. to a full hour
XA1440 Sync. at the Specified Time
Specified Time for Logger Splitting
XD
XDn:p n = -1 (switched off)
n = 0..1439 (time in minutes)
p = 1..6 (specified time number)
State of the instrument (Stop or Start)
S
S0 - STOP
S1 - START
Exposure Time
e
en - n = time in minutes  (1  480)
Measure Triggering mode
m
m0 - switched off (OFF)
m1 - Slope +
m2 - Slope –
m3 - Level +
m4 - Level –
m6 - Grad +
m7 - External
