SVAN 977A User Manual - Appendixes
Group name
Group
code
Code description
Source of the measure triggering
signal
s
s0 - RMS
Measure Triggering level in SLM mode
l
lx - x = level in dB (24  136)
Measure Triggering gradient
in SLM mode
O
Ox - x = gradient in dB/ms (1  100)
Measure Triggering level in VLM mode
n
nx - x = level in dB (60  200)
Measure Triggering gradient
in VLM mode
k
kx - x = gradient in dB/ms (1  100)
Logger Triggering mode
XT
XT0 - switched off
XT3 - Level +
XT4 - Level –
Logger Triggering level in SLM mode
XL
XLx - x = level in dB (24  136)
Logger Triggering level in VLM mode
Xy
Xyx - x = level in dB (60  200)
Logger Triggering
Number of records taken into account
before the fulfilment of the triggering
condition
XQ
XQx - x = number of records saved in logger
before the fulfilment of the triggering
condition; nn (0  50)
Logger Triggering
Number of records taken into account
after the fulfilment of the triggering
condition
Xq
Xqx - x = number of records saved in logger after
the fulfilment of the triggering condition;
nn (0  200)
RPM Measurement
Xr
Xr0 - switched Off
Xr1 - switched On
RPM Pulse
Xp
Xpn - n = Pulses/Revolution (1 ÷ 360)
RPM Unit
Xu
Xu0 - rps
Xu1 - rpm
Reference Level ACC
Xa
Xax - x = reference level (1  100) in µm/s
2
Reference Level VEL
Xv
Xvx - x = reference level (1  100) in nm/s
Reference Level DIL
Xd
Xdx - x = reference level (1  100) in pm
External IO Mode
Xx
Xx0 - Analog Out
Xx1 - Digital In
Xx2 - Digital Out
Xx3 - Analog In
External IO Function
Xz
Xz0 - Trigger Pulse
Xz1 - Alarm Pulse
External IO Active Level
Xc
Xc0 - Low
Xc1 - High
