SVAN 977A User Manual - Appendixes
Table B.1.4 Calibration settings
Word
number
Name
Comment
0
0xnn47
[47, nn=header’s length]
1
PreCalibrType
type of calibration performed prior to measurement:
0 - none
1 - BY MEASUREMENT
2 - BY SENSITIVITY
3 - FACTORY CALIBRATION
2
PreCalibrDate
date of calibration performed prior to measurement (cf. App. B.4)
3
PreCalibrTime
time of calibration performed prior to measurement (cf. App. B.4)
4
PreCalibrFactor
factor (*100 dB) of calibration performed prior to measurement
5
PostCalibrType
type of calibration performed after the measurement:
0 - none
1 - BY MEASUREMENT
2 - BY SENSITIVITY
3 - FACTORY CALIBRATION
0xFFFF - Calibration not performed
6
PostCalibrDate
date of calibration performed after the measurement (cf. App. B.4)
7
PostCalibrTime
time of calibration performed after the measurement (cf. App. B.4)
8
PostCalibrFactor
factor (*100 dB) of calibration performed after the measurement
…
…
…
Table B.1.5 USER’s text
Word
number
Name
Comment
0
0xnn03
[03, nn=specification’s length]
1…
title text
the user’s text (two characters in a word) finished with one or two
null bytes
Table B.1.6 Parameters and global settings
Word
number
Name
Comment
0
0xnn04
[04, nn=block’s length]
1
MeasureStartDate
measure start date (cf. App. B.4)
2
MeasureStartTime
measure start time (cf. App. B.4)
3
DeviceMode
device mode:
0 – Vibration Level Meter / Analyser (VLM)
1 – Sound Level Meter / Analyser (SLM)
4
DeviceFunction
device function:
1 – LEVEL METER,
2 – 1/1 OCTAVE analyser,
3 – 1/3 OCTAVE analyser,
6 – FFT analyser,
8 – RT60 analyser
5
MeasureInput
measurement input type:
2 – Microphone
5 – Accelerometer
