SVAN 977A User Manual - Appendixes
Word
number
Name
Comment
29
SplitTime[2]
Logger files splitting time:
-1 - off.
0:1439 - Time in minutes.
Valid only if SplitMode is equal 1440.
30
SplitTime[3]
Logger files splitting time:
-1 - off.
0:1439 - Time in minutes.
Valid only if SplitMode is equal 1440.
31
SplitTime[4]
Logger files splitting time:
-1 - off.
0:1439 - Time in minutes.
Valid only if SplitMode is equal 1440.
32
SplitTime[5]
Logger files splitting time:
-1 - off.
0:1439 - Time in minutes.
Valid only if SplitMode is equal 1440.
33
SplitTime[6]
Logger files splitting time:
-1 - off.
0:1439 - Time in minutes.
Valid only if SplitMode is equal 1440.
…
Table B.1.7 MEASUREMENT TRIGGER parameters
Word
number
Name
Comment
0
0xnn2B
[2B, nn=block’s length]
1
TriggerMode
trigger mode:
0 – Off,
1 – measurement on trigger SLOPE+
2 – measurement on trigger SLOPE–
3 – measurement on trigger LEVEL+
4 – measurement on trigger LEVEL–
6 – measurement on trigger GRAD+
7 – measurement on External trigger
2
TriggerSource
source of the triggering signal:
0 – LEQ/RMS(1) the LEQ/RMS result from the first profile
3
TriggerLevel
level of triggering (*100 dB)
4
TriggerGrad
gradient of triggering [dB/ms]
5
reserved
6
reserved
7
TriggerStep
trigger period given in 0.1 ms. If zero Step is equal to logger time-
step (cf. Table B.1.21)
5 – 0.5ms
…
