Svantek SVAN 977A - Page 180

180
SVAN 977A User Manual - Appendixes
Word
number
Name
Comment
10
FilterP[2]
filter type in the 2
nd
profile:
1 – Z,
2 – A,
3 – C,
5 – B
11
BufferP[2]
logger contents in the 2
nd
profile defined as a sum of:
0 – none,
1 – Peak,
2 – Max,
4 – Min,
8 – Leq,
16 – LR1,
32 – LR2
12
reserved
13
ProfileFlags[2]
flags in the 2
nd
profile
14
0xmm06
[06 = id, mm = sub-block’s length]
15
DetectorP[3]
detector type in the 3
rd
profile:
0 – IMPULSE,
1 – FAST,
2 – SLOW
16
FilterP[3]
filter type in the 3
rd
profile:
1 – Z,
2 – A,
3 – C,
5 – B
17
BufferP[3]
logger contents in the 3
rd
profile defined as a sum of:
0 – none,
1 – Peak,
2 – Max,
4 – Min,
8 – Leq,
16 – LR1,
32 – LR2
18
reserved
19
ProfileFlags[3]
flags in the 3
rd
profile
…
…
…
Table B.1.13 Special settings for profiles in the case of VLM mode
Word
number
Name
Comment
0
0xnn05
[05 = id, nn = block’s length]
1
0x0307
[used_profile, profile’s mask]
2
0xmm06
[06 = id, mm = sub-block’s length]
