SVAN 977A User Manual - Appendixes
Word
number
Name
Comment
19
ProfileFlags[3]
flags in the 3
rd
profile
…
…
…
Table B.1.14 RTF parameters
Word
number
Name
Comment
0
0xnn21
[21 = id, nn = block’s length]
1
Type [1]
type of 1
st
user filter:
0 - HIGHPASS, 1 - LOWPASS, 2 - BANDPASS
2
Rank [1]
rank of 1
st
user filter:
in the case of BANDPASS: 4
in other cases: 2
3÷4
Lower pole [1]
5÷6
Upper pole [1]
7
Type [2]
type of 2
nd
user filter:
0 - HIGHPASS, 1 - LOWPASS, 2 - BANDPASS
8
Rank [2]
rank of 2
nd
user filter:
in the case of BANDPASS: 4
in other cases: 2
9÷10
Lower pole [2]
11÷12
Upper pole [2]
13
Type [3]
type of 3
rd
user filter:
0 - HIGHPASS, 1 - LOWPASS, 2 - BANDPASS
14
Rank [3]
rank of 3
rd
user filter:
in the case of BANDPASS: 4
in other cases: 2
15÷16
Lower pole [3]
17÷18
Upper pole [3]
…
…
…
Table B.1.15 Marker parameters
Word
number
Name
Comment
0
0x0043
[43 = id, 00 = block’s length in the second word]
1
BlockLength
Block’s length
2
MarkerCount
Number of markers
3..7
MarkerName[1]
Name of 1st marker (10 characters length)
8
MarkerEvt[1]
1st marker event:
0 – Off
1 – On
9
MarkerPoint[1]
1st marker point:
0 – Off
1 – On
