Svantek SVAN 977A - Page 183

183
SVAN 977A User Manual - Appendixes
Word
number
Name
Comment
10..14
MarkerName[2]
Name of 2nd marker (10 characters length)
15
MarkerEvt[2]
2nd marker event:
0 – Off
1 – On
16
MarkerPoint[2]
2nd marker point:
0 – Off
1 – On
17..21
MarkerName[3]
Name of 3rd marker (10 characters length)
22
MarkerEvt[3]
3rd marker event:
0 – Off
1 – On
23
MarkerPoint[3]
3rd marker point:
0 – Off
1 – On
24..28
MarkerName[4]
Name of 4th marker (10 characters length)
29
MarkerEvt[4]
4th marker event:
0 – Off
1 – On
30
MarkerPoint[4]
4th marker point:
0 – Off
1 – On
…
…
…
Table B.1.16 Header of the statistical analysis
Word
number
Name
Comment
0
0xnn09
[09, nn=block’s length]
1
0x0307
[03=number of profiles, 07=active profiles mask]
2
0xmm0A
[0A, mm=sub-block’s length]
3
NofClasses[1]
number of classes in the first profile (120)
4
BottomClass[1]
bottom class boundary (*100 dB) in the first profile
5
ClassWidth[1]
class width (*100 dB) in the first profile
6
0xmm0A
[0A, mm=sub-block’s length]
7
NofClasses[2]
number of classes in the second profile (120)
8
BottomClass[2]
bottom class boundary (*100 dB) in the second profile
9
ClassWidth[2]
class width (*100 dB) in the second profile
10
0xmm0A
[0A, mm=sub-block’s length]
11
NofClasses[3]
number of classes in the third profile (120)
12
BottomClass[3]
bottom class boundary (*100 dB) in the third profile
13
ClassWidth[3]
class width (*100 dB) in the third profile
…
…
…
