SVAN 977A User Manual - Appendixes
Table B.1.22 Contents of the logger file
Word number
Name
Comment
0..(BuffLength/2-1)
result#1, result#2, ... result#(BuffLength/2-1)
Table B.1.23 Main results in SLM mode (saved in Summary Results Record)
Word
number
Name
Comment
0
0xnn07
[07, nn=block’s length]
1
0x0307
[used_profile, profile’s mask]
2
0xmm08
[08, mm=sub-block’s length]
3..4
MeasureTime
time of the measurement
5
Result[1][1]
Peak value in the 1
st
profile (*100 dB)
6
Result[1][2]
SEL value in the 1
st
profile (*100 dB)
7
Result[1][3]
Max value in the 1
st
profile (*100 dB)
8
Result[1][4]
Min value in the 1
st
profile (*100 dB)
9
Result[1][5]
Spl value in the 1
st
profile (*100 dB)
10
Result[1][6]
Leq value in the 1
st
profile (*100 dB)
11
Result[1][7]
Lden value in the 1
st
profile (*100 dB)
12
Result[1][8]
Ltm3 value in the 1
st
profile (*100 dB)
13
Result[1][9]
LTeq value in the 1
st
profile (*100 dB)
14
Result[1][10]
LR1 value in the 1
st
profile (*100 dB)
15
Result[1][11]
LR2 value in the 1
st
profile (*100 dB)
16
Result[1][12]
reserved
17
UnderRes[1]
under-range value in the 1
st
profile
18
ResultsFlags[1]
results flags:
b1 - if set to 1: overload occurred
b5,b4,b3: type of the result Lden
000 – Lden result is not available
001 – Ld result
010 – Le result
011 – Lde result
100 – Ln result
101 – Lnd result
110 – Len result
111 – Lden result
19
0xmm08
[08, mm=sub-block’s length]
20..21
OVL
overload time
22
Result[2][1]
Peak value in the 2
nd
profile (*100 dB)
23
Result[2][2]
SEL value in the 2
nd
profile (*100 dB)
24
Result[2][3]
Max value in the 2
nd
profile (*100 dB)
25
Result[2][4]
Min value in the 2
nd
profile (*100 dB)
26
Result[2][5]
Spl value in the 2
nd
profile (*100 dB)
27
Result[2][6]
Leq value in the 2
nd
profile (*100 dB)
28
Result[2][7]
Lden value in the 2
nd
profile (*100 dB)
