Svantek SVAN 977A - Page 188

188
SVAN 977A User Manual - Appendixes
Word
number
Name
Comment
29
Result[2][8]
Ltm3 value in the 2
nd
profile (*100 dB)
30
Result[2][9]
LTeq value in the 2
nd
profile (*100 dB)
31
Result[2][10]
LR1 value in the 2
nd
profile (*100 dB)
32
Result[2][11]
LR2 value in the 2
nd
profile (*100 dB)
33
Result[2][12]
reserved
34
UnderRes[2]
under-range value in the 2
nd
profile
35
ResultsFlags[2]
flags word for measurement cycle (cf. Table B.1.23 [18])
36
0xmm08
[08, mm=sub-block’s length]
37..38
reserved
39
Result[3][1]
Peak value in the 3
rd
profile (*100 dB)
40
Result[3][2]
SEL value in the 3
rd
profile (*100 dB)
41
Result[3][3]
Max value in the 3
rd
profile (*100 dB)
42
Result[3][4]
Min value in the 3
rd
profile (*100 dB)
43
Result[3][5]
Spl value in the 3
rd
profile (*100 dB)
44
Result[3][6]
Leq value in the 3
rd
profile (*100 dB)
45
Result[3][7]
Lden value in the 3
rd
profile (*100 dB)
46
Result[3][8]
Ltm3 value in the 3
rd
profile (*100 dB)
47
Result[3][9]
LTeq value in the 3
rd
profile (*100 dB)
48
Result[3][10]
LR1 value in the 3
rd
profile (*100 dB)
49
Result[3][11]
LR2 value in the 3
rd
profile (*100 dB)
50
Result[3][12]
reserved
51
UnderRes[3]
under-range value in the 3
rd
profile
52
ResultsFlags[3]
flags word for measurement cycle (cf. Table B.1.23 [18])
53
ResExtra[1]
LeqLF value in 0.01 dB
…
…
…
Table B.1.24 Main results in VLM mode (saved in Summary Results Record)
Word
number
Name
Comment
0
0xnn07
[07, nn=block’s length]
1
0x0307
[used_profile, profile’s mask]
2
0xmm08
[08, mm=sub-block’s length]
3..4
MeasureTime
time of the measurement
5
Result[1][1]
Peak value in the 1
st
profile (*100 dB)
6
Result[1][2]
P-P value in the 1
st
profile (*100 dB)
7
Result[1][3]
Max value in the 1
st
profile (*100 dB)
8
Result[1][4]
reserved
9
Result[1][5]
reserved
10
Result[1][6]
RMS value in the 1
st
profile (*100 dB)
11
Result[1][7]
reserved
