SVAN 977A User Manual - Appendixes
Word
number
Name
Comment
12
Result[1][8]
reserved
13
Result[1][9]
reserved
14
Result[1][10]
reserved
15
Result[1][11]
reserved
16
Result[1][12]
reserved
17
UnderRes[1]
under-range value in the 1
st
profile
18
ResultsFlags[1]
results flags:
b1 - if set to 1: overload occurred
19
0xmm08
[08, mm=sub-block’s length]
20..21
OVL
overload time
22
Result[2][1]
Peak value in the 2
nd
profile (*100 dB)
23
Result[2][2]
P-P value in the 2
nd
profile (*100 dB)
24
Result[2][3]
Max value in the 2
nd
profile (*100 dB)
25
Result[2][4]
reserved
26
Result[2][5]
reserved
27
Result[2][6]
RMS value in the 2
nd
profile (*100 dB)
28
Result[2][7]
reserved
29
Result[2][8]
reserved
30
Result[2][9]
reserved
31
Result[2][10]
reserved
32
Result[2][11]
reserved
33
Result[2][12]
reserved
34
UnderRes[2]
under-range value in the 2
nd
profile
35
ResultsFlags[2]
flags word for measurement cycle (cf. Table B.1.24 [18])
36
0xmm08
[08, mm=sub-block’s length]
37..38
reserved
39
Result[3][1]
Peak value in the 3
rd
profile (*100 dB)
40
Result[3][2]
P-P value in the 3
rd
profile (*100 dB)
41
Result[3][3]
Max value in the 3
rd
profile (*100 dB)
42
Result[3][4]
reserved
43
Result[3][5]
reserved
44
Result[3][6]
RMS value in the 3
rd
profile (*100 dB)
45
Result[3][7]
reserved
46
Result[3][8]
reserved
47
Result[3][9]
reserved
48
Result[3][10]
reserved
49
Result[3][11]
reserved
50
Result[3][12]
reserved
51
UnderRes[3]
under-range value in the 3
rd
profile
52
ResultsFlags[3]
flags word for measurement cycle (cf. Table B.1.24 [18])
…
…
…
