SVAN 977A User Manual - Appendixes
Table B.1.25 Statistical levels (saved in Summary Results Record)
Word
number
Name
Comment
0
0xnn17
[17, nn=block’s length]
1
0xpprr
[pp=used_profile, rr=profile’s mask]
2
N_stat_level
number of statistical levels = N
3+i*(pp+1)
nn[i]
number of the Lnn statistics;
i=0..N-1
3+i*(pp+1)+p
Lnn[i,p]
value of the Lnn statistics
for profile p (p=1..pp) (*100 dB)
…
…
…
Table B.1.26 1/x Octave analysis results (saved in Summary Results Record)
Word
number
Name
Comment
0
0xnn4B, 0xnn4C,
0xnn4D
[block_id, nn=block_length]
0xnn4B - averaged spectrum results,
0xnn4C - min. spectrum results,
0xnn4D - max. spectrum results
1
0x0101
[used_profile, profile’s mask]
2÷(2+i-1)
Octave[i]
1/x Octave[i] value (*100 dB); i=1÷(NOct+NTot)
…
…
…
Table B.1.27 FFT analysis results (saved in Summary Results Record)
Word
number
Name
Comment
0
0x0052, 0x0053,
0x0054
[block_id, nn=00]
0x0052 - averaged FFT results,
0x0053 - min. FFT results,
0x0054 - max. FFT results
1
BlockLength
block length
2
0x0101
[used_profile, profile’s mask]
3..4
N
number of spectra per averaging
5÷…
FFT[i]
values of i
th
FFT line and Total results (*100 dB);
…
…
…
Table B.1.28 Results of the statistical analysis in profiles (saved in Summary Results Record)
Word
number
Name
Comment
0
0x010B
[0B, prof_mask#1]
1
SubblockLength
2 * number of classes in the first profile + 2
2..3
Histogram[1][1]
the first counter in the first profile
4..5
Histogram[1][2]
the second counter in the first profile
