Svantek SVAN 977A - Page 191

191
SVAN 977A User Manual - Appendixes
.....
.....
.....
0
0x020B
[0B, prof_mask#2]
1
SubblockLength
2 * number of classes in the second profile + 2
2..3
Histogram[2][1]
the first counter in the second profile
4..5
Histogram[2][2]
the second counter in the second profile
.....
.....
.....
0
0x040B
[0B, prof_mask#3]
1
SubblockLength
2 * number of classes in the third profile + 2
2..3
Histogram[3][1]
the first counter in the third profile
4..5
Histogram[3][2]
the second counter in the third profile
.....
.....
.....
Table B.1.29 Results of the statistical analysis performed in 1/x Octave mode (saved in Summary Results
Record)
Word
number
Name
Comment
0
0x0114
[14 = id, 01 = number of the histogram]
1
Sub-blockLength
2 * NofClasses + 2 (242)
2÷3
Histogram[1][1]
first counter for the first 1/x OCTAVE filter
4÷5
Histogram[1][2]
second counter for the first 1/x OCTAVE filter
...
...
...
0
0x0214
[14 = id, 02 = number of the histogram]
1
Sub-blockLength
2 * NofClasses + 2 (242)
2÷3
Histogram[2][1]
first counter for the second 1/x OCTAVE filter
4÷5
Histogram[2][2]
second counter for the second 1/x OCTAVE filter
...
...
...
...
...
...
0
0xnn14
[14 = id, nn = NofHist = number of the last histogram]
1
Sub-blockLength
2 * NofClasses + 2 (242)
2÷3
Histogram[nn][1]
first counter for the last 1/x OCTAVE filter
4÷5
Histogram[nn][2]
second counter for the last 1/x OCTAVE filter
...
...
...
Table B.1.30 RPM results (saved in Summary Results Record)
Word
number
Name
Comment
0
0xnn1F
[1F = id, nn = block’s length]
1
Rpm[0]
RPM[0]
2
Rpm [1]
RPM[1]
3
RpmMax [0]
RPM Max[0]
4
RpmMax[1]
RPM Max[1]
