Main menu
The main Menu contains the headers of six sections (sub-menu), which group
configuration settings by feature. The main Menu is opened after pressing the
<Menu> (<Shift> + <ENTER>) key. The main Menu list contains the following
sections: Function, Measurement, Display, File, Instrument and
Auxiliary Setup.
Recent Items list
A double pressing of the <Menu> key opens the list of recently used menu items.
This enables accessing most frequently used lists of parameters quickly, without
the necessity of passing through the whole menu path.
Selecting position
The desired position in the menu list is
selecting with the ▲ / ▼ key.
Opening position
After the selection of the desired position in
the menu list, press the <ENTER> key to open
it. After this operation, a new sub-menu,
option list, parameter list or information screen
appears on the display.
List of parameters
The list of parameters contains parameters the value of which is selected from
the available range or set.
• The desired position in a list is accessed with the ▲ / ▼ key.
• Changing value in a selected position is performed with the ◄ / ► key.
• The <ENTER> key saves all performed changes in the list of parameters.
If the parameter has a numerical value, you can speed up a selection by pressing the ◄ / ► key and keeping it
pressed by more than 2 seconds. In this case, the parameter value starts to change automatically until the you
release the pressed buttons.
You may change the numerical parameter value with a larger step (usually 10) with the ◄ / ► key pressed
together with <Shift>.
List of options
The option list consists of different options, from which only one may be
selected. The selection of the option is performed in the following way. Highlight
the desired option with the ▲ / ▼ key and then press <ENTER>. This option
becomes active and the list is closed. After re-entering this list again, the last
selected option will be marked.
