SVAN 977A User Manual - Appendixes
f [Hz]
Case effect of
SA 277 for 0 deg
incidence angle
Compensation filter
“Airport”
Compensated case effect of
SA 277 for 0 deg incidence
angle (Airport)
6309.57
-1.18
1.32
0.14
6493.82
-1.03
1.22
0.19
6683.44
-0.91
1.08
0.17
6878.60
-0.76
0.93
0.17
7079.46
-0.63
0.75
0.12
7286.18
-0.42
0.56
0.14
7498.94
-0.27
0.37
0.10
7717.92
-0.05
0.18
0.13
7943.28
0.10
0.01
0.11
8175.23
0.16
-0.11
0.05
8413.95
0.16
-0.18
-0.02
8659.64
0.07
-0.17
-0.10
8912.51
-0.07
-0.09
-0.16
9172.76
-0.20
0.07
-0.13
9440.61
-0.32
0.28
-0.04
9716.28
-0.41
0.53
0.12
10000.00
-0.51
0.79
0.28
10292.01
-0.76
1.03
0.27
10592.54
-0.96
1.24
0.28
10901.84
-1.20
1.40
0.20
11220.18
-1.34
1.53
0.19
11547.82
-1.59
1.66
0.07
11885.02
-2.04
1.86
-0.18
12232.07
-2.64
2.20
-0.44
12589.25
-3.49
2.72
-0.77
12956.87
-4.41
3.45
-0.96
13335.21
-5.53
4.33
-1.20
13724.61
-6.55
5.27
-1.28
14125.38
-8.23
6.14
-2.09
14537.84
-9.88
6.83
-3.05
14962.36
-11.79
7.23
-4.56
15399.27
-13.10
7.27
-5.83
15848.93
-13.89
6.89
-7.00
16311.73
-13.55
6.08
-7.47
16788.04
-12.67
4.89
-7.78
17278.26
-12.26
3.46
-8.80
17782.79
-12.20
2.04
-10.16
18302.06
-12.29
0.97
-11.32
18836.49
-12.40
0.43
-11.97
19386.53
-12.55
0.33
-12.22
19952.62
-12.76
0.36
-12.40
