1.2.2.2.2.2 Weight and inertia of the encoder rings
Weight Inner Ring Outer Ring
Circulo 7 13.339 g 19.621 g
Circulo 9 23.402 g 30.949 g
Inertia Inner Ring Outer Ring
Circulo 7 0.025 Kg*cm² 0.087 Kg*cm²
Circulo 9 0.130 Kg*cm² 0.2981Kg*cm²
1.2.2.2.2.3 Drilling patterns
Circulo 7
