SYNAPTICON SOMANET Circulo 7 - Mode Specific Bits of the Statusword; Internal Limit Active Bit

tr target reached
ila internal limit active
oms operation mode specific
ms manufacturer specific
4.1.7.3.2 Mode specific bits of the Statusword
Mode of operationMode of operation
1313
1212
1111
1010
88
Profile Position
Following
error
Set-point
acknowledge
Internal limit
Active
Target
reached
N/A
Profile Velocity
N/A
Speed bit
Profile Torque
N/A
Cyclic Synchronous
Position
Target position
ignored
Cyclic Synchronous
Velocity
Target velocity
ignored
Cyclic Synchronous
Torque
Target Torque
ignored
Homing
N/A
4.1.7.3.3 Internal limit Active bit
The values that are limited by this bit differ in each mode:
Limiting object Limited value Operating
modes
Max torque (0x6072) Torque demand value (0x6074) All
Max torque (0x6072) Target torque (0x6071)
Torque offset (0x60B2)
PT / CST
Max. motor speed (0x6080) Velocity demand value (0x606B) CSP / PP
Max. motor speed (0x6080) Profile velocity (0x6081) PP
Max. motor speed (0x6080) Target velocity (0x60FF)Velocity offset (0x60B1). CSV / PV
Software position limit (0x607D) Position demand value (0x6062) CSP/PP
Legend:
