SYNAPTICON SOMANET Circulo 7 - Encoders and IO; Encoder Overview

1.2.2.1.2 Encoders and IO
1.2.2.1.2.1 Encoder overview
Important
One encoder has to be mounted on the motor side for commutation purpose. An encoder on a gear
out side can not be used for commutation!
Circulo 7
Circulo 9
