1.2.1.3.1 Current as a function of mounting temperature
Operation with mounting temperature cooler than specified above can increase the technically possible
maximum continuous current and related performance specifications, as shown in the figure below.
Operation with mounting temperature hotter than specified is possible in a limited extent. However, the
maximum continuous current and related performance specifications derate heavily in that case - see figure
below.
