1.5.4.3.2.7 EtherCAT port
1.5.4.3.2.7.1 EtherCAT IN Port
Pin-out
Pin Name Type Function
1 * TX+ O Differential transmit output
2 TX- O Differential transmit output
3 GND P Ground
4 RX+ I Differential receive input
5 RX- I Differential receive input
* Pin 1 is on left
