1.3.4.3.3 Connector mating parts and cable lengths

Connector

description

Manufacturer Mating part

number

Crimping

Contact

Cable

Safe brake port JST ZER-02V-S SZE-002T-P0.3 0.08-0.21 mm² / 28-24

AWG

Safe digital I/O port JST GHR-06V-S SSHL-002T-P0.2 0.05-0.13mm² / AWG 30-

Please observe the maximum allowed cable lengths:

Connection Maximum wire length

STO-SBC 30 m
