1.5.1.3 LED signals
1.5.1.3.1 Overview
SOMANET Circulo has several LEDs that show the servo drive’s state or indicate errors.
Attention
Please note that in the current revision the heatsink covers the LEDs completely.
All occuring errors are also reflected in the
Error Report
Object.
For your reference the position of the LED with the heatsink removed is given in the picture below.
1.5.1.3.1.1 Legend
Symbol Explanation
Off
Constantly luminous
Single flashes (1 pulse per second)
Slow blinking (3 pulses per second)
