Input voltage, logic 0 0-5 V
Galvanic isolation 2 kV Isolation voltage
Input current Max. 6 mA (@24 VDC)
Test pulse toleration (OSSD output pulses) Max. 1 ms
Reverse voltage protected Yes
Allowed discrepancy between digital inputs 100 ms
See safety diagnostics
De-activation time TBD
Safe brake output (SBC)
Number of digital outputs 2 (dual-channel safety output for one brake
system)
Max. output voltage Servo drive main power supply (48 VDC)
Min. output voltage 0 V
Max. current. 1 A
Max. peak current. 4 A
Digital output (STO-SBC diagnostic
output)
Galvanic isolation 2 kV Isolation voltage
Max. current 100 mA
Max. continuous voltage across the output 27 V
Max. peak voltage across the output 35 V
Reverse voltage protected Yes
Max. delay after STO-SBC activation 50 ms
Attention
Servo drives including STO-SBC module shall be used only in Pollution Degree environments class PD 2
according to IEC 61800-5-1: During normal operation only non-conductive pollution may occur,
temporarily occurring conductivity caused by condensation may only be expected when the servo drive
is out of operation.
