Incremental Encoder max
frequency
1.4 MHz (supports up to 14,000 rpm with a 4,096 resolution
incremental encoder)
Hardware protections Overcurrent
Overvoltage
Undervoltage
Overtemperature
[1]
PWM deadtime
PWM shoot through
Dimensions (see also
dimension drawings)
Inner diameter: 20 mm
Outer diameter: 72.2 mm
Height: 21.3 mm
Inner diameter: 40 mm
Outer diameter: 92.2 mm
Height: 22.3 mm
Weight (without encoder rings) 92 g 133 g
Operating temperature 0 … 60°C ambient air (inside the enclosure)
0 … 70°C on the mounting surface (typically B-side / bearing flange of
the motor)
Max. installation altitude 2000 m
Storage temperature -35 to 85°C
Humidity Max 90 % rH
Sensors on-board 3 x I (two phases measured, one computed)
U
t
t
Encoder port 1 1 x BiSS-C / SSI
Encoder port 2
1 x ABI / Fast ABI
[2]
/ ABI / BiSS-C / SSI / Half-Duplex / A-Format /
HALL
Brake power output 1A @ 48V
Brake peak current 4A
Digital I/O 5x Digital IO (3.3/5V)
1x Digital Output (3.3/5V)
1x Digital Input (24V)
phase
DC
mosfet
core
