SYNAPTICON SOMANET Circulo 7 - Page 702

CSV
CST
Note
In Profile Position mode, the master does not send a new calculated position at each cycle, instead, the
slave computes the intermediate positions itself directly at the trajectory generator.
Therefore, the objects sent back from the slave to the master are different than in CSP.
