23 [OUT] Mimics Switch On Disabled (sod) Bit of Statusword
24 [OUT] Mimics Quick Stop (qs) Bit of Statusword
25 [OUT] Mimics Warning (w) Bit of Statusword
Name Index:Sub Type Bit
Size
Options Unit Access PDO
Mapping
Pin 1 0x2210:1 USINT 8
Disabled 0
[IN] General
Purpose
2
[OUT] General
Purpose
3
[IN] Home Switch
(Active High)
4
[IN] Home Switch
(Active Low)
5
[IN] Limit Switch
Positive (Active
High)
6
[IN] Limit Switch
Positive (Active
Low )
7
[IN] Limit Switch
Negative (Active
High)
8
[IN] Limit Switch
Negative (Active
Low)
9
[IN] Interlock -
Disable
Operation (Active
Low)
10
[IN] Fault Reset
(Active High)
11
[IN] Interlock -
Fault Reaction
(Active Low)
12
[IN]
Timestamped
Rising Edge
(Active High)
13
[OUT] Target
Reached
14
[OUT] Internal
limit Active
15
readwrite
