[IN] Limit Switch
Negative (Active
High)
8
[IN] Limit Switch
Negative (Active
Low)
9
[IN] Interlock -
Disable
Operation (Active
Low)
10
[IN] Fault Reset
(Active High)
11
[IN] Interlock -
Fault Reaction
(Active Low)
12
[IN]
Timestamped
Rising Edge
(Active High)
13
[OUT] Target
Reached
14
[OUT] Internal
limit Active
15
[OUT]
Timestamped
Triggered Output
16
[OUT] Position
Triggered Output
(Pulse)
17
[OUT] Fault 18
[OUT] Switched
On
19
[OUT] Ready to
Switch On
20
[OUT] Operation
Enabled
21
[OUT] Voltage
Enabled
22
[OUT] Switch On
Disabled
23
[OUT] Quick Stop 24
[OUT] Warning 25
Pin 5 : DIO [Without Pull Down Resistor]
Name Index:Sub Type Bit
Size
Options Unit Access PDO
Mapping
Pin 6 0x2210:6 USINT 8 readwrite
