To set the embroidery speed
90
Chapter 5
3-2. To set embroidery speed within speed limit section (Revolution limit)
Set the maximum speed of the section where the embroidery speed is restricted.The area where speed was
restricted in the design is surrounded by the following function code.
3-2-1. Screen
3-2-2. How to operate
The following is an example that the maximum speed of the section between the function codes Low_S to
Low_E is set to "700".
(1) To open screen
(2) To select maximum speed
Function Name Function Code
Low Speed Start Stitch Low_S
Low Speed End Stitch Low_E
2 Revolution Limit
F2
500
Low Speed Code [rpm]
Maximum speed of section between function codes
Low_S to Low_E
)
2 Revolution Limit
6(76(7
700
6(76(7
