Necessary works after replacing the frame
152
Chapter 6
2. Necessary works after replacing the frame
2-1. To change frame type
2-1-1. Screen
C
Frame Type
7 Frame type
Tubular
Current frame type
When selecting "Tubular (W)", "Border (W)" in TWMX-C, the maximum speed will be limited
at 1000 rpm. When selecting "X-ext (W)", the revolution limit will be the following value.
High speed: 700 rpm
Low speed: 300 rpm
Moreover, when selecting "X-ext (W)", Auto jump will be set forcibly, and the setting range
will be 2.0 to 4.0 mm. (Initial value is 4.0 mm.)
Machine type Frame Type
TFMX-IIC TYPE-2
Border, Tubular (including the pocket frame), Cap 2, Frame
holder, Cylinder
TFMX-C
Border, Tubular (including the pocket frame), Cap, Auto clamp B,
Auto clamp T, Cylinder
TWMX-C
Border (W), Tubular (W) (including the pocket frame), Cap, Auto
clamp B, Auto clamp T, X-ext (W)
TFMX (L) Border
