TAJIMA TWMX-C - Name of each Part; TFMX-C Single-Head Machine

Name of each part
14
Chapter 2
1. Name of each part
1-1. TFMX-C single-head machine
8. Emergency stop switch(→p.22)
9. Main shaft motor
10. Head
11. Needle Base LED Lamp(→p.23)
12. Rotary hook
13. Stand (option)
1. Thread course
2. Color change system
3. Operation panel(→p.18)
4. X-axis motor
5. Start switch(→p.68)
6. Stop switch(→p.68)
7. Power switch(→p.34)
Only main sections are shown here. For details, refer to the separate parts list.
It is described as "TFMX-C".
