TAJIMA TWMX-C - To Return the Frame (Frame Back); to Advance the Frame (Frame Forward); To Switch Frame Back; Frame Forward

To return the frame (Frame Back) / to advance the frame (Frame Forward)
146
Chapter 6
1. To return the frame (Frame Back) / to advance the frame (Frame Forward)
1-1. To switch Frame Back / Frame Forward
1-1-1. Screen
1-1-2. How to operate
The following is an example of setting frame forward.
(1) To open screen
(2) To select FF (Frame Forward)
3 Frame Back/Frame Forward
C
FB
NO
1
39628
FB/FF
Stop code
Stitches
FB/FF Stitch Unit
Stitch Counter
1/3/5
Switching of FB (Frame Back) / FF (Frame Forward)
To execute by Stop code(→p.147)
To specify the number of stitches and execute(→p.147)
To change the frame feed amount(→p.149)
Current number of stitches. It is displayed only and
cannot be changed.
&
3 Frame Back/Frame Forward
6(76(7
FF
6(76(7
