Functions concerning optional device
206
Chapter 8
3. Functions concerning optional device
3-1. To make the air compressor available for use (Air Pressure Sensor)
Set this function when the following optional devices are equipped.
Auto Clamp Frame
Sequin device IV
Lochrose embroidery device
3-1-1. Screen
3-1-2. How to operate
The following is the example of making Air compressor available for use.
(1) Set to main screen.
(2) To press F3 key while pressing SET
(3) To press F3 key
YES: To use air compressor
NO: Not to use
When you use specified option, select "YES". Selecting "NO" could damage Sequin
device and/or the machine by moving down of Sequin device when Air pressure is
decreased in the middle of stitching.
3 Air Pressure Sensor
NO
CAUTION
!
6(76(7
)
2 Weak Brake
)
3 Air Pressure Sensor
NO
