TAJIMA TWMX-C - To Move the Frame Automatically at the Start, in the Middle and the End of Embroidery

To move the frame to the position registered
167
Chapter 6
1
2
3
4
5
6
7
8
9
10
11
5-2. To move the frame automatically at the start, in the middle and the end of embroidery
This function is the setting to move the frame automatically so that replacement of the frame, works for
applique and change of fabric to be stretched can be performed easily.
(1) At the start of embroidery, by operating the bar switch or the start switch, the frame will pass from the
offset start position [A] through the offset middle position [B] and move to the design start position [C].
(2) During embroidery, the frame will return from the color change point [D] to the offset start position [A]
through the offset middle position [B]. After performing works for applique here, the frame will move to
the color change point [D] through the offset middle position [B], then start embroidery again by switch
operation.
(3) When embroidery is finished, the frame will pass from the design end point [E] through the offset middle
position [B], then move to the offset start position [A].
5-2-1. Explanation on the screen
[A]
[C]
[B]
[B]
Embroidery starts During embroidery
[E]
[A]
Completion of embroidery
[D]
2 Needle Bar Selection
1
2
3
4
5
6
5
3
4
2
1
3
B
Offset mark
After step 2 is finished, the frame will return to the
offset start position [A] automatically. To move the
frame, the setting of "Automatic offset" is necessary.
(→p.165)
If "Automatic Offset" is not set, the frame will move to
the design start position [C].
