Decision of an embroidery design and the color change sequence
50
Chapter 4
4. Decision of an embroidery design and the color change sequence
4-1. To decide embroidery design (Data Setting)
Select the design in the machine memory and enable to embroider.
4-1-1. Screen
[a] Folder layer
The root folder and folder on the first level of the machine memory can be displayed.
[b] Folder
Folder name can be changed.(→p.178)
[c] Design registered in the machine memory
1 Data Input (Memory)
A
Group 1 Group 2 Group 3
Group 5Group 4
4
******
****
***
[c]
[b]
[a]
The capacity of the machine memory is 200
designs at the maximum (up to 2,000,000
stitches).
Group 1
: Root folder
: Folder Group 1 to 5 (First level)
Design name (up to 8 characters)
Total stitch number of design
File name
G001.TCF
TAJIMA_W
14117
2[CR]
Machine memory registration No.
With setting of design repetition
With setting of scaling up/down/reversion of design
To Next Page
