5-3. To return the frame to the offset start position manually (Return to the offset origin)
This function makes the frame return to the offset start position in the middle of embroidery when you
stopped the machine. It it possible to operate only when Automatic offset is set. The offset middle position is
not passed.
5-3-1. Screen
5-3-2. How to operate
The following is an example of executing offset return.
(1) To open screen
(2) To execute offset return
To return the frame to offset start position
: Not to execute
: To execute
When performing this operation, do not put your hands etc. on the machine table. Moving
frame could injure you.
Pressing SET will move the frame. To
return to the original position, perform
"Manual offset".
(→p.156)
6 Return to the offset origin
CAUTION
!
'
6 Return to the offset origin
