TAJIMA TWMX-C - Tfmx-IIC Type-2

Name of each part
16
Chapter 2
1-3. TFMX-IIC TYPE-2
9. Power switch(→p.34)
10. Head(→p.66)
11. Slim cylinder bed
12. Rotary hook
13. Stop switch(→p.68)
14. Start switch(→p.68)
15. Main shaft motor
1. Thread course
2. Change unit A
3. Change unit B
4. Y-axis motor
5. X-axis motor
6. Transformer
Existence/absence differs depending on
spec.
7. Operation panel(→p.18)
8. Emergency stop switch(→p.22)
Alternative
1
2
3
5
6
7
8
9
15
14
13
12
11
Only main sections are shown here. For details, refer to the separate parts list.
4
10
