TAJIMA TWMX-C - To Set All Head Sewing Start Point (Frame Back All Head Sew)

To return the frame (Frame Back) / to advance the frame (Frame Forward)
150
Chapter 6
(2) To move the cursor to "FB/FF Stitch unit"
(3) To select frame feed amount
1-4. To set All Head Sewing Start Point (Frame Back All Head Sew)
This function applies to 2 or more head machines. This setting sets “All Head Sewing Start Point After Frame
Back” and “Whether the machine stops at the position just before All Head Sewing Start Point or not”.
1-4-1. Explanation on the screen
[a] Frame Back All head Sew
ALL:
0 - 9:
[b] The machine stops at the position just before All Head Sewing Start Point.
YES: To stop
NO: Not to stop
5
6(76(7
5 Frame Back All Head Sew
C
4 ALL/0-9[st]
Halt Frame Back
NO
YES/NO
[a]
[b]
All heads sew the whole section of frame back.
When ALL is selected, "Halt Frame Back" is fixed to NO.
All Head Sewing Start Point
The value indicates the number of stitches from a frame back start point.
