223
Trouble examples and Corrective actions
Chapter 9
1
2
3
4
5
6
7
8
9
10
11
2-4. To suspend the error head
When it becomes impossible to perform embroidery by all heads due to malfunctioning of tension
base card,this working makes the remaining heads perform embroidery by making the head with
occurrence of trouble become suspended head.It corresponds only to 2 or more head machine.
2-4-1. Working procedure
(1) Detach the wiring cover.
To detach the wiring cover, be sure to turn OFF the power. Card that generates high
voltage is attached to the back face of the square pipe. There could be danger of electric
shock.
To Next Page
