TAJIMA TWMX-C - Cording Device

To make optional device available for use
196
Chapter 8
1-5. Cording Device
This is a setting for making coding device (KB-2M) available for use. For details of the device, refer to the
separate manual "KB-2M (L&R)".
1-5-1. Screen
[a] Use of the device
YES: To use
NO: Not to use
[b] Equipped needle bar position
1(st needle): Equipped to the right side
12 (th needle): Equipped to left side (in case of 12-needle machine)
The last needle will be displayed.
1-5-2. How to operate
The following is an example of equipping Cording device to the left side.
(1) To open screen
(2) To use cording device
F3
YES/NO
NO
3 Cording
Needle No.
1
[a]
[b]
)
3 Cording
6(76(7
YES
6(76(7
