To return the frame to the original position
158
Chapter 6
3-3. To prevent displacement of design when the power is shut off during operation
(Power resume)
This function works on condition that the frame origin is memorized correctly. If it is wrong, the frame will not
return to the correct position.
3-3-1. Screen
3-3-2. How to operate
The following is an example of executing Power resume.
(1) Set to main screen.
(2) Press F2 key while pressing SET key.
(3) Press F2 key.
When performing this operation, do not put your hands etc. near the needle or on the
machine table. Moving needle bar or frame could injure you.
SET
8 Power Resume
F2
ATH
To return the frame to several stitches before the
position where power was shut off
: Not to execute
: To execute
: To execute after thread trimming
)
To Next Page
