To embroider the same design repeatedly
101
Chapter 5
1
2
3
4
5
6
7
8
9
10
11
[d] Number of repeats in vertical
[e] Interval in vertical (mm)
[f] Priority embroidering direction (horizontal/vertical)
It is the setting which direction is given priority to embroider, horizontal(X) or vertical(Y).
[g] To embroider the next design after thread trimming
It is displayed only and cannot be changed.
6-1-2. How to operate
The following is an example that repeat pattern "pb", the number of repeats in horizontal "3", interval in
horizontal "-60", the number of repeats in vertical "2", interval in vertical "-50", priority direction "X" are set.
(1) To open screen
(2) To select repeat pattern
When performing this operation, do not put your hands etc. on the machine table. Moving
frame could injure you.
Repeat direction will be decided by code. Selecting "-" will
perform embroidering at front.
To Next Page
