To set details of optional device
203
Chapter 8
1
2
3
4
5
6
7
8
9
10
11
2-1-3. How to operate
The following is the example of feeding out sequin chips of the right side Sequin device one by one.
(1) Set the tension base switch to "Middle" position. (It should not be suspended head.)
(2) To open screen
(3) To move the cursor to "Sequin chip feed"
(4) To select R (Right-side Sequin device)
(5) To feed sequin chips
Every time raising the tension base switch will feed out sequin chips one by one.
When performing this operation, do not put your hands etc. near the needle or on the
machine table. Otherwise, moving up/down of the Sequin Device or moving right/left of
the needle bar case could injure you.
Pressing SET will perform color
change to the sequin needle.
