TAJIMA TWMX-C - Page 254

240
Spec. of the machine
Chapter 11
SQ12
In case of 2 or more head machines
(1) Detach the acrylic board.
(2) Change connection of the connector CN11 on the power supply card.
CN11
[Connection of CN11]
In case of 100 V series
In case of 200 V series
Label No.3
Power supply
Acrylic board
card
